Eye Bolts DIN 444 Type B
DIN 444 Type B Eye Bolts
DIN 444 Dimensions for Type B Eye Bolts
| Size | L (mm) | B (mm) | D2 (H9) (mm) | D3 (H14)(mm) | R (mm) | S (H12)(mm) | M.B.L (KN) |
|---|---|---|---|---|---|---|---|
| M6 x 1.0 | 40 | 18 | 6 | 14 | 4 | 7 | 12.1 |
| M6 x 1.0 | 60 | 18 | 6 | 14 | 4 | 7 | 12.1 |
| M8 x 1.25 | 50 | 22 | 8 | 18 | 4 | 9 | 22.0 |
| M8 x 1.25 | 70 | 22 | 8 | 18 | 4 | 9 | 22.0 |
| M10 x 1.5 | 60 | 26 | 10 | 20 | 4 | 12 | 34.8 |
| M10 x 1.5 | 80 | 26 | 10 | 20 | 4 | 12 | 34.8 |
| M12 x 1.75 | 70 | 30 | 12 | 25 | 6 | 14 | 50.6 |
| M12 x 1.75 | 100 | 30 | 12 | 25 | 6 | 14 | 50.6 |
| M16 x 2.0 | 80 | 38 | 16 | 32 | 6 | 17 | 94.2 |
| M16 x 2.0 | 120 | 38 | 16 | 32 | 6 | 17 | 94.2 |
| M20 x 2.5 | 100 | 46 | 18 | 40 | 6 | 22 | 147.0 |
| M20 x 2.5 | 140 | 52 | 18 | 40 | 6 | 22 | 147.0 |
| M24 x 3.0 | 120 | 54 | 22 | 45 | 10 | 25 | 211.8 |
| M24 x 3.0 | 160 | 60 | 22 | 45 | 10 | 25 | 211.8 |
